Construction Begins on I-210 Gold Line Bridge

This rendering of a "linear foot bridge" over the 210 looks kind of futuristic. To see a pic of the existing conditions click on after the jump.

(The following is a press advisory from the Gold Line Foothill Construction Authority.  We usually don’t reprint press releases, or even talk about this rail extension out to the SGV, but I wanted to pass on the news that construction work on the Foothill Extension is well underway.  And, I wanted to see what you thought of the bridge design. – DN)

After nearly a year of design work, permit approvals and hiring of subcontractors, crews will start work on the I-210 Gold Line Bridge next week. The 584-linear foot bridge crosses over the eastbound lanes of the I-210 Freeway between Baldwin and Santa Anita Avenues, and will facilitate connection between the existing Sierra Madre Villa Station in East Pasadena and the future Arcadia Station. It is the first component of the Metro Gold Line Foothill Extension light rail project from Pasadena to Azusa to move from design to construction.

Over the next few months, crews will clear the center and southern freeway medians, build a 500 foot long temporary retaining wall, and then start work on the massive foundations for the bridge structure. Intermittent late-night closures of the Eastbound I-210 Freeway will be necessary during the year-long bridge construction. The Metro Gold Line Foothill Extension Construction Authority will issue regular construction notices to update the community on bridge construction activities and schedules.

This is what the 210 looks like before construction.

Community members can sign up to receive construction alerts via email or text message on the Authority’s website at www.foothillextension.org. Information is also available over the phone on the 24-hour project information hotline – (855) 446-1160.

The I-210 Bridge is scheduled to be completed in July 2012, in time for the alignment contractor to start installing the track, utilities, systems and more.

  • El Barto

    pure awesome

  • Bob Davis

    Caption for the first photo calls it a “pedestrian bridge”–not so, it’s for an electric railway, and pedestrians would not be welcome.  Also, this is the first bit of actual construction for the smaller part of the job.  The main contract is expected to be awarded later this month.

  • Does “linear foot bridge” not mean its for peds?  That would be my bad…

  • Bob Davis

    “584-linear foot bridge” refers to how long it will be (feet as in traditional units of measurement, not what Fats Waller called “pedal extremities”).  Or one could say, “linear feet” as opposed to “square feet”.  I should also add that even though it’s out in the SGV, it’s still in Los Angeles County.  (SGV, where many of us look upon “Carmageddon” as something of purely academic interest)

  • Anonymous

    Are you retarded or something, Damien?

    Why would pedestrians want to walk along a railway track to a beautiful freeway median? The visualization you posted shows a train running on it.

  • About time

    Finally! So many walkable old towns will finally get train service again!

  • Iforgot

    You are missing the rendering with the complete removal of the 210. That would be an awesome picture.

  • Dontlooknow10-blog

    It looks like a prop for an Easter movie. Appropriate segue for Glendora and all of it’s gumdrop-like ficus trees.

  • Pump

    Oh man, that thing’s ugly. Way overscaled for the setting.
